Create a bounding box with specified aspect ratio and buffer

Source: R/fun_bbox.R
atl_bbox.Rd

This function generates a bounding box for a given geometry with a specified aspect ratio. Additionally, it allows applying a buffer to expand or contract the bounding box.

Usage

atl_bbox(data, x = "x", y = "y", asp = "16:9", buffer = 0)

Arguments

data

An sf or sfc object for which the bounding box is calculated or a data.table with x- and y- coordinates.

x

A character string representing the name of the column containing x-coordinates. Defaults to "x".

y

A character string representing the name of the column containing y-coordinates. Defaults to "y".

asp

A character string specifying the desired aspect ratio in the format "width:height". Default is "16:9".

buffer

A numeric value specifying the buffer distance to be applied to the bounding box. Positive values expand the bounding box, while negative values shrink it. Default is 0.

Value

A bounding box (bbox), represented as a named vector with xmin, ymin, xmax, and ymax values.

Author

Johannes Krietsch

Examples

library(sf)
#> Linking to GEOS 3.12.2, GDAL 3.9.3, PROJ 9.4.1; sf_use_s2() is TRUE

# Create a simple geometry
geom <- st_as_sfc("POLYGON((0 0, 1 0, 1 2, 0 2, 0 0))")

# Create a bounding box with a 16:9 aspect ratio
atl_bbox(geom, asp = "16:9")
#>      xmin      ymin      xmax      ymax
#> -1.277778  0.000000  2.277778  2.000000

# Create a bounding box with a 1:1 aspect ratio and a buffer of 0.5 units
atl_bbox(geom, asp = "1:1", buffer = 0.5)
#> xmin ymin xmax ymax
#> -1.0 -0.5  2.0  2.5
